Instructions for compressor nebulizer Ulyser air+ vp-d2
Precautions
Before use, make sure that the nebulizer is in good condition and has no visible signs of wear.
If in doubt, contact your dealer.
This nebulizer should only be used for its intended purpose and in accordance with
to this instruction manual. Using the device for purposes other than its intended purpose is dangerous. The manufacturer or the Authorized Representative of Yuria-Pharm LLC is not liable for any damages caused by violation of the rules of operation of the device or use for purposes other than its intended purpose.
Children under 14 years of age, persons with physical or mental disabilities or persons without appropriate training may only use the nebulizer under the supervision of competent adults. Children are not allowed to play with the device.
This nebulizer should only be used as directed by your doctor. Be sure to follow your doctor's instructions regarding the type, dose, and schedule of inhalation.
Before connecting the device, make sure that the power supply parameters are
correspond to those indicated on the device.
It is forbidden to use the nebulizer in the presence of flammable mixtures of anesthetics with air, oxygen or nitrous oxide, harmful vapors, volatile
substances or flammable gases.
Never leave the nebulizer running unattended. After the procedure is complete
Turn it off and unplug it from the power outlet.
You must handle the device with care, protect it from accidental impacts, sharp
temperature changes, humidity, dust, direct sunlight and heat sources.
The nebulizer is impact resistant, however, a fall from a height of 1 meter or more can damage the device.
In case of disruption of normal operation and/or malfunction, turn off the device and do not attempt to repair it yourself. Only experienced specialists are allowed to repair the nebulizer.
You must turn the nebulizer on and off with dry hands.
Do not pull on the power cord to unplug the power supply from the outlet.
Unwind the power cable and place it at a safe distance from heat sources.
Protect the power cord from damage. If damaged, it must be replaced.
Always use the “O/I” (ON/OFF) button to turn off
nebulizer, then unplug the power supply from the outlet.
Immediately after using the device and before cleaning, the unit must be removed.
power supply from the outlet.
Do not immerse the nebulizer in water or pour water or other liquids on it.
If the nebulizer falls into water, do not try to remove it. Unplug the device immediately.
Do not reuse the device after it has been submerged in water.
Do not dry the device or its accessories in a microwave oven.
It is forbidden to use the device in wet places, as well as when
temperature below +10 ºC or above +40 °C.
If the solution contains surfactants or has high viscosity
(e.g. solubilizers or expectorants) the degree of nebulization may be reduced. Low solution temperature may also cause a decrease in the degree of nebulization.
Do not lie down while inhaling. Do not use the device while sleeping.
Do not tilt the nebulizer chamber at an angle greater than 45°.
Use accessories only from the manufacturer of this nebulizer.
Before each use, make sure that all parts are installed correctly.
Do not turn on the nebulizer if the air supply tube is bent.
Make sure the air filter is clean and installed correctly.
Do not cover the nebulizer with towels or blankets during use.
Description of the compressor nebulizer
Compressor (main unit).
Air outlet hole.
Air tube.
"O/I" switch.
Power cable connector.
Nebulizer chamber.
Nebulizer chamber holder.
Air filter cover.
Pillow.
DC adapter (power supply).
Nebulizer chamber cover.
The upper part of the nebulizer chamber.
Bumper.
The lower part of the nebulizer chamber.
Technical specifications
Specifications and appearance are subject to change without prior notice.
Trade name
Compressor nebulizer Ulyser™ Air+, VP-D2
Model
VP-D2
Accessories (may be sold separately)
1. Nebulizer chamber VP-D2
2. VP-D2 mouthpiece
3. Nasal Inhaler VP-D2
4. Children's mask VP-D2
5. Adult mask VP-D2
6. VP-D2 Air Tube
7. Air filter VP-D2
8. VP-D2 DC adapter
9. Storage case
Power supply parameters
100-240 V, 50/60 Hz
Operating conditions
Temperature: from +10 ºC to +40 ºC
Relative humidity: 30 to 85%
Atmospheric pressure: 70–106 kPa (kPa)
Storage conditions
Temperature: from -20 ºC to +50 ºC
Relative humidity: 30 to 85%
Atmospheric pressure: 50–106 kPa (kPa)
Classification of installation and use
Main product: portable.
The portable product is not intended for use in the presence of a mixture of flammable anesthetics and oxygen.
Product type (component/part of the main product/equipment/system)
Power consumption
Main product: Input power parameters: 12 V DC, 1 A.
Noise level
Nebulizer chamber volume
≤8 ml (ml)
Spraying speed
≥0.20 ml/min (ml/min)
Particle size
MMAD ≤5 µm (μm)
Overall dimensions (length × width × height)
Model VP-D2
144 × 78 × 67 mm (mm)
Weight (without battery)
Model VP-D2: 260 g (g) (without nebulizer chamber and air tube)
Environmental pollution
Class 2
Overvoltage category
Category II
Altitude
≤3000 m (m)
Degree of protection against ingress of water and foreign particles
IP21
Compressor air flow
4 l/min (l/min)–7 l/min (l/min)
Spray pressure
20 kPa (kPa)–80 kPa (kPa) (2.9 psi–11.7 psi)
Working time
25 min (min) ON/40 min (min) OFF
Expected service life of the nebulizer (when used to spray products twice a day for 10 minutes)
About 500 hours
Using a nebulizer
Before using the device for the first time, clean it as described in the “Maintenance and Disinfection” section.
In order to pour the therapy agent into the nebulizer chamber, you need to turn the chamber lid counterclockwise and open it according to the picture.
Remove the cap and make sure the spray tip (or baffle) is properly attached to the top of the chamber, and pour the correct amount of therapy into the bottom of the chamber as recommended by your doctor. Do not pour more than 8 ml (ml) of therapy into the nebulizer chamber.
After the therapy agent is poured into the nebulizer chamber, screw the top of the chamber as shown in the picture below. Place the nebulizer chamber on a clean and dry surface.
Make sure that the power supply specifications match those indicated on the nebulizer body. Connect the DC adapter to the device, and then plug the adapter power supply into a power outlet.
Securely connect one end of the air tube to the nebulizer chamber and the other end to the appropriate compressor fitting (air outlet).
Wear a mask or nasal cannula, or use a mouthpiece (depending on your doctor's recommendations).
Turn on the nebulizer using the “O/I” button.
Wear a mask that fits snugly against your face and completely covers your mouth and nose, or use a mouthpiece or nasal aspirator (depending on your doctor's recommendations).
During the procedure, breathe in and out as normal. Sit up straight and relax. Do not lie down during the procedure. Do not tilt the nebulizer chamber more than 45˚.
Stop inhalation if you feel unwell.
After inhalation, turn off the nebulizer by pressing the “O/I” button. Unplug the power supply and disconnect the adapter cable from the nebulizer.
Disconnect the air tube from the nebulizer chamber and compressor. As with most nebulizers, a small amount of solution remains in the nebulizer chamber after inhalation – a residual volume that is not atomized. This is normal.
Pour out the remaining therapy agent from the nebulizer chamber and follow the steps described in the “Maintenance and Disinfection” section.
This nebulizer can operate continuously for 25 minutes, after which it must be turned off to cool down. The nebulizer can be turned on again after 40 minutes.
The nebulizer body may become warm during operation – this is normal.
Maintenance and disinfection
Wash your hands thoroughly before cleaning and disinfecting accessories.
After each use, thoroughly rinse all parts of the nebulizer chamber and remove any remaining therapy agent and any contamination.
Accessories should be washed before and after each use.
The compressor housing (main unit) and air tube should be wiped with a clean, damp cloth. It is strictly forbidden to wash the compressor housing under running water. The compressor housing is not protected against the penetration of liquids.
Cleaning the accessories: Rinse all accessories except the air tube, compressor, and DC adapter in warm water, then air dry.
Disinfection. To disinfect accessories other than the air tube, compressor and DC adapter, you can use appropriate disinfectants according to the manufacturer’s instructions. The nebulizer chamber, mouthpiece and nasal insufflation tip can be disinfected by boiling in water for 15–20 minutes. Make sure there is always water in the container during boiling. Do not use autoclaves, ethylene oxide gas sterilizers or low-temperature plasma sterilizers. After washing, air dry the accessories.
In order to remove moisture from the air tube, you need to connect one end to the compressor fitting, leave the other free, and turn on the nebulizer for a few seconds.
Microbial contamination. If the patient is sick, he can cause microbial contamination of the nebulizer accessories, in which case it is necessary to use personal inhalation accessories and a separate nebulizer chamber (you should always consult a doctor).
Do not bend the air tube. Do not wrap the DC adapter cable around the nebulizer body.
Troubleshooting
Malfunction/
problem
Possible cause
Elimination
There is no power after setting the switch to the “I” (ON) position.
DC adapter not connected
Set the switch to the “O” (OFF) position. Insert the DC adapter plug into the corresponding socket on the nebulizer. Turn on the nebulizer
Low spray level or no spray after compressor is turned on
There is no solution in the nebulizer chamber.
There is too much or not enough solution in the nebulizer chamber.
Pour the required amount of solution into the nebulizer chamber.
Nebulizer chamber baffle is incorrectly installed or missing
Make sure the bumper is installed correctly
Nebulizer chamber assembled incorrectly
Correctly assemble the nebulizer chamber and correctly install the components for inhalation
Blocked compressor fitting (air outlet)
Clean the compressor and air outlet
Patient holding nebulizer chamber at a high angle
Hold the nebulizer chamber correctly.
Do not tilt the nebulizer chamber at an angle greater than 45°.
Air tube connected incorrectly
Make sure the air tube is properly connected to the compressor fitting and to the nebulizer chamber.
The air tube is severely bent or damaged.
Air tube blocked
Make sure the air tube is not bent, twisted or blocked. Check the air tube for damage. If the air tube is damaged, it must be replaced.
Dirty air filter
Replace the old air filter with a new one
The nebulizer body is very hot.
The nebulizer is covered (e.g. with a cloth)
During operation, it is forbidden to cover the nebulizer with a blanket, towel or any other materials.
Continuous operation for more than 25 minutes
The maximum duration of operation of the nebulizer at one time is 25 minutes. The next time the product can be turned on is after 40 minutes.
Loud noise during nebulizer operation
The air filter cover is not installed correctly.
Install the air filter cover correctly.
Make sure the air filter cover is not blocked.
Guidelines and manufacturer's declaration
The installation and commissioning of this product are carried out in accordance with the instructions contained in the accompanying documentation.
The immunity test level for the basic safety and essential performance of electrical medical equipment and systems should be selected based on the high probability of maintaining the basic safety and essential performance, and in accordance with the professional medical facility environment, home conditions and special environments depending on the intended use.
Home settings are the patient's place of residence or other places where patients are, with the exception of professional medical facilities where medical personnel are constantly present (e.g. schools, residences, hotels, etc.).
For example: as specified in Table 6 of the IEC 60601-1-2:2014 standard for electrical medical equipment, a typical mobile phone with a maximum output power of 2 W (W) gives d = 3.3 m (m) at a resistance level of 3 V/m (V/m).
A1 Electromagnetic interference – for all equipment and systems.
Guidelines and manufacturer's declaration regarding electromagnetic interference
The compressor nebulizer Ulyser™ Air+, VP-D2 is intended for use in the electromagnetic environments specified below. The owner or user of the compressor nebulizer Ulyser™ Air+, VP-D2 should assure that it is used in such an environment.
Electromagnetic radiation test
Meets the requirements
Electromagnetic environment. Guidance.
Radiofrequency radiation
CISPR 11
Group 1
In the compressor nebulizer Ulyser™ Air+, VP-D2, radio frequency radiation is used only to ensure the normal operation of the product. Therefore, the level of radio frequency radiation from the product is very low and cannot affect the operation of electronic equipment located near the product.
Radiofrequency radiation
CISPR 11
Class B
The compressor nebulizer Ulyser™ Air+, VP-D2 is intended for use in all types of medical institutions, except domestic ones and those directly connected to the low-voltage power supply network that supplies buildings used for domestic purposes.
IEC 61000-3-2
"Emission of harmonic current components"
Class A
IEC 61000-3-3 “Voltage fluctuations/flicker”
Meets the requirements
A2 Electromagnetic immunity. Home healthcare systems and equipment.
The compressor nebulizer Ulyser™ Air+, VP-D2 is intended for use in the electromagnetic environments specified below. The owner or user of the compressor nebulizer Ulyser™ Air+, VP-D2 should assure that it is used in such an environment.
Electromagnetic Radiation Immunity Test
Test according to IEC 60601-11
Compliance level
Electromagnetic environment guidelines
IEC 61000-4-2 "Electrostatic discharge (ESD)"
±8 kV (kV), contact
±2 kV (kV), ±4 kV (kV), ±8 kV (kV), ±15 kV (kV), air
±8 kV (kV), contact
±2 kV (kV), ±4 kV (kV),
±8 kV (kV), ±15 kV (kV), air
The floor in the room should be wooden, concrete or covered with ceramic tiles. If the floor is covered with synthetic material, the minimum relative humidity should be 30%.
IEC 61000-4-4 “Electrical fast transients or bursts”
±2 kV (kV) for power lines
±2 kV (kV) for power lines
The quality of electricity must meet the requirements for commercial or domestic consumption.
Voltage surges IEC 61000-4-5
±1 kV (kV) phase to phase
±2 kV (kV) phase - ground
±1 kV (kV) phase to phase
±2 kV (kV) phase - ground
The quality of electricity must meet the requirements for commercial or domestic consumption.
IEC 61000-4-8 "Immunity to power frequency magnetic fields (50/60 (Hz) Hz)"
30 A/m (A/m)
30 A/m (A/m)
Power frequency magnetic field characteristics should meet requirements for commercial and medical facilities
IEC 61000-4-11 "Immunity to voltage dips, short interruptions and variations"
0% UT;
0.5 cycle
At 0°, 45°, 90°, 135°, 180°, 225°, 270° and 315°
0% UT;
0.5 cycle
At 0°, 45°, 90°, 135°, 180°, 225°, 270° and 315°
The power quality should be that of a typical commercial or residential environment. If the VP-D2 nebulizer is operated in an area subject to frequent power outages, the product should be powered from an uninterruptible power supply or a battery.
IEC 61000-4-6 "Immunity to Conducted Disturbances"
3 V (V) rms
from 150 kHz to 80 MHz
3 V (V) rms
The manufacturer should consider reducing the minimum spatial separation based on risk management data and use higher levels of interference immunity for the reduced minimum spatial separation. The minimum spatial separation for higher levels of interference immunity is calculated using the following equation:
Where:
P – maximum power in watts W (W);
d – minimum spatial separation in meters m (m);
E – level of resistance to electromagnetic interference, V/m (V/m).
IEC 61000-4-3
"Radio frequency radiation"
10 V/m (V/m)
from 80 MHz to 2.7 GHz
10 V/m (V/m)
Note: UT is the AC mains voltage before the test voltage is applied.
Utilization
The product and its accessories may come into contact with hazardous body fluids, infectious material and become contaminated during its service life. For this reason, the product and its accessories should be decontaminated before disposal or transportation. You can help protect the environment!
Please remember to follow local regulations: hand over unused electrical equipment to the appropriate waste disposal center.
Storage conditions
Store the device at a temperature of -20 ºC to +50 ºC out of the reach of children, as it contains small parts that can be swallowed. The compressor nebulizer should be stored in a dry room, protected from excessive humidity (over 85%), dirt and direct sunlight. The permissible atmospheric pressure during storage is 50–106 kPa (kPa).
Never place heavy objects on the device storage box.
Guarantee
The compressor nebulizer Ulyser™ Air+, VP-D2 is intended for individual use.
If you have any problems with your nebulizer, you do not need to immediately return it to the place of sale. It is recommended to first seek advice from the specialists of the Authorized Representative in Ukraine (information is available on the website https://ulaizer.com.ua/ua/) or send a message to the email address: uf@uf.ua.
The nebulizer is guaranteed for 2 (two) years, provided it is used as intended and in accordance with the operating instructions.
The warranty applies only to the compressor (main unit) and does not apply to the nebulizer chamber and other accessories, as the service life of accessories depends significantly on the intensity of their use.
The warranty period for the nebulizer chamber, masks and other accessories is 180 hours, provided that the operating instructions are followed. However, if they change color, it is recommended to replace them.
To confirm that the nebulizer warranty is valid, you must provide a receipt from the point of sale or warranty card.
In case of violation of the rules of operation and maintenance, as well as improper use of the nebulizer, the warranty is void.
The warranty is also voided in the event of independent repairs or modifications to the device's design.
Warranty service is limited to the actions specified above. Any other warranty service is not provided.
Name and address of the manufacturer
VAPO Healthcare Co., Ltd., South Unit of Second Floor, Building B, No. 99 Yudai West Road, High Tech District, Kunshan, Suzhou, 215301, Jiangsu, People's Republic of China.
(VAPO Healthcare Co., Ltd., Southern unit of third floor, building B, No. 99 Yudai West Rd, High tech district, KunShan, Suzhou, 215301, Jiangsu, PR China.)
If you have any comments about a medical product or would like to leave a review, please use one of the following methods:
send a letter to feedback@uf.ua;
send a text message using Viber, Telegram or WhatsApp to +38 (095) 275-33-01;
call +38 (095) 275-33-01 (calls are charged according to your operator's rates) or +38 (0800) 401-771 (free from any number in Ukraine).
